TSP 700II |
| Printer Method |
Direct Line Thermal |
| Print Speed |
48 Receipts Per Minute (250 mm/sec) |
| Printer Case Color |
Putty or Gray |
| Model Available |
Auto Cutter Only |
Print Resolution
(Vertical x Horizontal) |
203x203 dpi, 406x203 dpi |
| Two Color Print Capability |
Red & Black / Blue & Black / Green & Black (Two color thermal paper required) |
| No. of Columns |
48 / 64 or 58 / 71 (Depends on Paper Width)
Includes 1st column print for lottery applications |
| Font Size |
12 x 24 |
| Character Set |
ANK 95, 32 Int 128 Graphic |
| International Code Pages |
Star Mode=40. ESC/POS™= 6 + 1 blank allowing an additional character page to be added |
| Bar Codes |
9 versions / PDF417, QR, Maxicode Options |
| Line Spacing |
3 mm or 4 mm or programmable |
Paper Specifications
Width
Thickness
Roll Diameter
Easy-Load
Paper Out Sensor
Black Mark Sensor
Paper Low
Maximum Print Width |
80mm standard, 82.5 and 58mm with paper guide
0.065 ~ 0.15 mm
Up to 100 mm
"Drop-In & Print"
Standard
Standard
Standard
80mm paper = 72mm, 82.5mm paper = 80mm, 58mm paper = 52mm |
| Top Margin |
13 mm minimum default (3mm selectable via Memory Switch Utility) |
| External Paper Feed Support |
Yes |
| Auto Cutter |
Guillotine (Full or Partial Cut Selectable) |
| Cover Open Sensor |
Yes |
| Logo Store Capacity |
2 Mbit Flash ROM with Graphic Management Software |
| Flash ROM |
16 Mbit |
| Label Support |
Yes; Black timing marks between labels required |
| Power Supply |
External; Requires PS60A External Power Supply |
| Drivers Available |
Windows® XP 32 Bit, Vista 32/64 Bit, Windows 7 32/64 Bit, Server 2008 32/64 Bit, XP Embedded, CE, POSReady 2009, OPOS™, JavaPOS™, USB Vendor Class, Linux™, Mac OS X, StarIO SDK |
| Digitally Signed (WHQL) |
Yes |
| Swappable Interfaces |
Yes |
| Connectivity |
Serial, Parallel, USB, Powered USB, Ethernet, WiFi
Virtual Serial Port to USB, Virtual Serial Port to Ethernet |
| Emulation Modes |
Star Mode, ESC/POS™ |
| Peripheral Drive Circuit |
2 circuits, (24V max. 1A), 1 Compulsion input |
| Power Consumption |
Average 1.8 Amp. Printing, 0.15 Amp. Standby
Requires PS60A External Power Supply |
| Operating Conditions |
Temperature: 5ºC to 45ºC
Humidity: 10% - 90% RH (without condensation) |
| Storage Conditions |
Temperature: -20ºC to 60ºC
Humidity: 10% - 90% RH |
Dimensions
Weight |
147mm(W) x 213(D) x 148(H) mm
1.75 kg |
| Safety Standards |
UL, C-UL, TüV, FCC, VCCI, EN55022, CE, Gost |
Reliability MCBF
Auto Cutter |
60 Million Lines
2 Million Cuts |
| Included with Printer |
Installation CD with Drivers, Configuration Utility, and Value Add Utility modeled afterfuturePRNT Software, Wall Mount Bracket, Interface Cover, 58mm Paper Guide, Power Switch Cover |
| Warranty |
Three Year Warranty |
| Options |
External Power Supply (PS60A)
Splash Proof Cover (SPC-T700)
Kitchen Buzzer (BU01-24-A)
Vertical Stand (VS-T700)
Swappable Interfaces
24V Mobile Power Supply
Swap-A-Star Extended Warranty Program (US and Canada) |
